随着时代的发展和科技的进步，我们的家用电器日益增多，对电能的需求也越来越大，线路的延展越来越长，拓扑结构越来越复杂。下面地埋探测厂家就来讲讲一种地埋电缆探测设备的制作方法。

With the development of the times and the progress of science and technology, our household appliances are increasing, the demand for electric energy is also growing, the extension of lines is getting longer and longer, and the topology is getting more and more complex. The following is a method of making buried cable detection equipment.

由于地下敷设电缆不占空间，现代化大都市大多采用地埋电缆代替高空架设电缆，尤其是居民区、商业区、工业区等地方。而现代化大都市大多采用地埋电缆代替高空架设电缆，这就给电缆故障检修、增容等带来诸多不便。

Because underground cable laying does not take up space, most modern metropolises use buried cables instead of overhead cables, especially in residential areas, commercial areas, industrial areas and other places. Most modern metropolises use buried cables instead of overhead cables, which brings a lot of inconvenience to cable troubleshooting and capacity expansion.

特别是设计施工图纸遗失，或者缺少相关文档资料的，更是大大增加了施工难度。这就导致了一旦出现故障，不能快速判断电缆路径以及电缆的深度，不能快速对电缆路径和故障点进行定位，往往需要人工大面积挖掘，费时费力。主要提供了一种地埋电缆探测设备用以上述背景技术中提出的技术问题。

In particular, the loss of design and construction drawings or the lack of relevant documents greatly increases the construction difficulty. This results in that once a fault occurs, the cable path and cable depth cannot be quickly determined, and the cable path and fault point cannot be quickly located. It often requires manual excavation in a large area, which is time-consuming and laborious. This paper mainly provides an underground cable detection equipment to solve the technical problems raised in the above background technology.

一种地埋电缆探测设备，包括有发射模块以及依次电连接的信号采集模块、信息处理模块、微处理器和显示模块,所述发射模块包括有承接箱，所述承接箱的内部固定有发射机，所述发射机与所述承接箱的内壁之间形成有储纳槽，所述信号采集模块包括有连接杆，所述连接杆位于所述储纳槽的槽体内部，所述连接杆的底端固定有连接头，所述连接头的内部固定感应天线和第二感应天线。

An underground cable detection device includes a transmitting module, a signal acquisition module, an information processing module, a microprocessor and a display module which are electrically connected in turn. The transmitting module includes a receiving box, the inside of which is fixed with a transmitter. A storage tank is formed between the transmitter and the inner wall of the receiving box. The signal acquisition module includes a connecting rod which is located inside the tank body of the storage tank, The bottom end of the connecting rod is fixed with a connector, and the first induction antenna and the second induction antenna are fixed inside the connector.

具体操作方式如下：

The specific operation mode is as follows:

使用探测设备对电缆进行测量时，将待测电缆与发射模块1中的发射机12相连接，使得发射机12输出16种频率的正弦交流信号,再手持连接杆22以及接收器31移动电缆的大致安装区域，由于连接杆22底端通过连接头23固定有感应天线24和第二感应天线25，感应天线24与第二感应天线25处于同一平面内，并且保持相互垂直时，左右同步平行移动感应天线24以及第二感应天线25，当感应天线24以及第二感应天线25处于待测地埋电缆正上方时接收到的正弦交流信号强；感应天线24接收到的信号为待测地埋电缆到地面的电势，第二感应天线25收到的信号为待测地埋电缆到地面再加上感应天线24以及第二感应天线25之间的电势。

When using the detection equipment to measure the cable, first connect the cable to be tested with the transmitter 12 in the transmission module 1, so that the transmitter 12 outputs sinusoidal AC signals of 16 frequencies, and then hold the connecting rod 22 and the receiver 31 to move to the approximate installation area of the cable. Since the bottom end of the connecting rod 22 is fixed with the first inductive antenna 24 and the second inductive antenna 25 through the connector 23, When the first induction antenna 24 and the second induction antenna 25 are in the same plane and are kept perpendicular to each other, the first induction antenna 24 and the second induction antenna 25 are moved synchronously and horizontally. When the first induction antenna 24 and the second induction antenna 25 are directly above the buried cable to be measured, the received sinusoidal AC signal is strong; The signal received by the first inductive antenna 24 is the potential between the buried cable to be measured and the ground, and the signal received by the second inductive antenna 25 is the potential between the buried cable to be measured and the ground plus the potential between the first inductive antenna 24 and the second inductive antenna 25.

上述结合附图对进行了示例性描述，显然具体实现并不受上述方式的限制，只要采用了方法构思和技术方案进行的这种非实质改进，或未经改进将构思和技术方案直接应用于其他场合的，均在保护范围之内。更多相关内容就来我们网站http://www.binzhouhengtong.com进行咨询了解吧！

The above is illustrated with the accompanying drawings. Obviously, the specific implementation is not limited by the above methods. As long as such non substantial improvement is made by adopting the method concept and technical solution, or the idea and technical solution are directly applied to other occasions without improvement, they are within the scope of protection. More relevant content will come to our website http://www.binzhouhengtong.com Consult and understand!
